EN11

www.afx-light.com

M000-M255 Change the Y-axis motor running speed (M000~M255) up or down, and press EN-

TER to save.

FAN0-FAN1 Fan setting: FAN0 will start the fan when it is powered on, FAN1 will start the fan

when it reaches the set temperature protection point, and press ENTER to save.

T040-T070 Change the temperature parameter up or down (40°~70°), press the enter ENTER

to save.

Send Send the factory setting parameters of the machine up or down to all other lamps

connected in parallel with three-core signal lines; conrm the sending parameters

and press the menu key for 5 seconds to exit, or deny the parameters and press

the ENTER key to cancel the sending.

DMX512 CONSOLE

After power on, set the address codes of all xtures, and then connect all xtures in parallel to the

DMX512 console via three-core signal cables. The address codes will stop ashing, indicating that

the DMX512 console signal has been sent to the xtures. Use DMX512 to control the xtures.

See the DMX channel charts on page 2-3 of the manual.

MODE EFFECT

See the MODE channel chart on page 3-6 of the manual.

Tip: Mode code 9~120, you can push and pull RGBW to change the background color.

SPECIFICATONS

Input voltage ................................................................................................................... 100-240V~ 50/60Hz

Consumption ............................................................................................................................................. 180W

Light source ......................................................................................................... 10x 15W RGBW 4-in-1 LEDs

Operating modes ..................................................................................... DMX512, auto, master-slave, RDM

DMX channels ................................................................................................................................... 7 / 13 / 43

Dimmer .............................................................................................................................Linear 0-100% 32bit

Strobe frequency .................................................................................................................................... 1~30Hz

IP .................................................................................................................................................................. IP20

Dimensions .......................................................................................................................... 980 x 180 x 80mm

Weight ........................................................................................................................................................ 6.1kg

IMPORTANT NOTE: Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local

authorities or your dealer about the way to proceed.
