EN7
www.afx-light.com
This time lighting hour Thistimelightinghour(accuratetominute)
Error information Instruction
Reset fail, uart error Driver board doesn’t respond. There is problem in the uart commu-
nication line of display board and driver board. Or the driver board
problem.
Pan reset fail X photoelectric switch, or X Motor problem
Tilt reset fail Y photoelectric switch, or Y Motor problem
Pan Hall error Problem in X Hall
Tilt Hall error Problem in Y Hall
Motor Colour reset fail There is problem in Color wheel hall, or Color wheel motor
Motor Gobo reset fail There is problem in Gobo wheel hall, or Gobo wheel motor
Lamp control fail Lamp light on or off fail, there is problem in ballast or lamp
lamp hours too long, pls re-
place
The total lamp light hour over the Maximum lamp light hour in “high
class” menu. Remind the user change the lamp in time. And then
clear the lamp light hour in “high class”, timer reset
2.5 Advanced interface
Set a password to prevent non-authorized persons to operate the unit. Default password is “UP
DOWN UP DOWN”. Press “Enter” to check the password
Option Instruction
Y Hall state 0 means the magnet closure, 1 means the magnet stagger
Color wheel hall state 0 means the magnet closure, 1 means the magnet stagger
Gobo wheel hall state 0 means the magnet closure, 1 means the magnet stagger
X coding disc state 2digit, each digit corresponding to the photoelectricity
switch on the coding disc
Y coding disc state 2digit, each digit corresponding to the photoelectricity
switch on the coding disc
X coding disc step va-
lue
Running in positive direction, the step value adding, Run-
ning in negative direction, the step value reduced
Y coding disc step va-
lue
Running in positive direction, the step value adding, Run-
ning in negative direction, the step value reduced
Reset ca-
libration
X calibration X Fine
Adjustmentrange:-128~+127,
+0showsnoadjustment
Y calibration Y Fine
Color wheel calibra-
tion
Colorwheelne
Gobo wheel calibra-
tion
Gobowheelne
Prism zoom calibra-
tion
Prismzoomne
Maximum
lighting
hour
0-9999hours. The alarm sounded once over the maximum
lamp lighting hour
Reset ligh-
ting hour
After clear the lamp light hour, timer reset
