EN 6
© Copyright LOTRONIC 2022
X Reverse OFF
ON
Y Reverse OFF
ON
X/Y Exchange OFF
ON ChangethechannelofX/Yaxis(includeX/YFine)
No DMX Signal KEEP According to the original state continues to run
CLEAR Motor reset, stop running
Display screen
protect
ON Closing backlight after free 30seconds
OFF Backlight still lighting
Lamp on start up OFF Reset directly after Power on, lamp off (need to use the
menu or control table to manual let lamp light)
ON Lamp light directly after power on, And must wait for the
lamp light up success then reset
Restore to default
set
Pressokkeyseetheconrmationdialogbox,PressOKkey
to restore to default set
2.3. Manual control interface
Thisinterfaceusesforcontrolpresentlight,andthenautoenterintomastermode(didn’treceive
DMX signal, sent the dmx signal to slave light)
Manualmenuwillaccordingtostandard12Channeltosetmenu(Dimmerandstrobenotused)
Option Instruction
1CH. X 0~255 Press OK key into edit state, Then selected hundreds place. Press
up or down, change address code. Press OK key again, selected ten
place and edit. Press OK key again, select the rst place and edit.
Press it to exit the edit state.
…… 0~255
12CH. Macro
function
0~255
13CH. Reset Pressokkeyseetheconrmationdialogbox,PressOKkeytoreset
surface, all motors reset
2.4 System information
Option Instruction
Software version Current software version
DMX Channel Enter into sub-surface, using value and percentage show the DMX
channel to check
System error record
Note: Sometimes it not
the installation problem
of Hall or optocoupler. It is
because the motor cable
inversely connect
IftheredERRindicatorlightlighton,itmeansxturerunningerror,
and enter the sub-surface to check the details. Press “Clear” to emp-
tytheerrorrecordafternishcheck
Total using hour Totalusinghour(accuratetominute)
This time using hour Theusinghourfromthepoweron(accuratetominute)
Total lighting hour Totallightinghour(accuratetominute)
