Replace the s-bag when S-BAG
indicator lights up in red
(green light: bag is OK, yellow
light: soon time to replace bag).
Open the dust compartment
cover by pulling the S-BAG
button.
Pull the cardboard handle to
close and remove the s-bag®
Insert a new s-bag® by pushing
the cardboard straight down
in its tracks. Close the lid. If the
s-bag® is not properly placed or
is missing, the lid will not close.
Replace/clean the filter when
filter indicator lights up in red.
Green light indicates that the
filter is ok. It lights up briefly
when you start the vacuum
cleaner.
After replacing the filter, close
the filter lid until it is clicked
back into place. If the filter lid
comes off, position the hinges at
the bottom and push the filter lid
until it is clicked back into place.
For deep cleaning on carpet, change
the nozzle setting with the slider
to Carpet mode. Icon illustrates
recommended floor type. Move
the nozzle forward. The front
light turns on automatically
after a few seconds. When the
nozzle is not used, the light turns
off automatically after a few
seconds.
Replace the motor filter when
dirty or after every 5th s-bag.
Push the filter holder down and
pull it out. Exchange the filter
and close the lid.
Disconnect the nozzle from
the tube. Clean with the hose
handle.
Disconnect the nozzle from the
tube and remove entangled
threads etc by snipping them
away with scissors. Use the hose
handle to clean the nozzle.
Pull the textile tab to take
out 3in1 tool. The tool has
3 functions, see pictures on next
page.
After usage, put it back in its
place.
Pull the FILTER button to open
the filter lid. Use original s-filters.
Remove the filter and check the
reference on the frame to define
type. Replace with a new filter
or clean it. Rinse the inside (dirty
side) in lukewarm tap water. Tap
the filter frame to remove the
water. Repeat the process four
times.
NB: Always change the s-bag when S-BAG indicator is illuminated or has
red light even if the s-bag is not full (it may be blocked) and after using
carpet cleaning powder. For best possible performance, use the Ultra Long
Performance bag which is especially developed for your cleaner. Other synthetic
s-bags can also be used. Do not use paper dust bags! www.s-bag.com
NB: Do not use cleaning agents. Avoid touching the filter surface. Let the filter
dry completely (min. 24 h in room temperature) before putting back ! Change the
washable filter at least once a year or when it is very dirty or damaged. Do not
remove the L-shaped foam under the filter.
NB: When you start the cleaner after filter replacement, It takes 10 seconds
before the FILTER indicator turns green or turns off.
When you start the cleaner after s-bag replacement, It takes 10 seconds before
the S-BAG indicator turns off or turns green.
After cleaning, push the
REWIND button to rewind the
cable.
Use parking position on the side
(A) or underneath (C) to carry
and store the cleaner. At the
back (B) when you pause (save
your back).
Adjust suction power: The
cleaner starts in AUTO mode
(automatic power regulation).
AUTO indicator is illuminated
on the display and LOW/HIGH
indicator pulses. To regulate
power manually press +/- button
on handle. Press AUTO button to
return to auto-function.
Pull out the power cord and
plug it into the mains. Press
the ON/OFF button to turn the
cleaner on/off. Indicators light
up, LOW/HIGH indicator lights
up from left to right and back.
Press the ON/OFF button on
the remote control to turn the
cleaner on/off.
REPLACING THE DUSTBAG, S-BAG®
VACUUMING WITH THE UNIVERSAL NOZZLE
CLEANING THE UNIVERSAL NOZZLE
CLEANING THE TURBO NOZZLE
3IN1 ACCESSORY TOOL
START/STOP THE VACUUM CLEANER AND ADJUST
SUCTION POWER
REPLACING THE FILTERS
PARKING POSITIONS
