5) Mic/Line Switch: OUT is Mic Input mode; IN is Line Input mode
which bypasses the mic preamp stage to accomodate line-level
signals. The green LED near the switch will indicate when the Line
Input mode is engaged.
6) Phantom Power (P48) Switch: OUT is off; IN applies full-spec
P48 phantom power to the input. The red LED near the switch will
indicate when P48 phantom power is engaged.
7) Polarity Invert Switch: OUT is normal; IN is inverted. The green
LED near the switch will indicate when the Polarity Invert mode is
engaged.
8) Mic Gain Rotary Switch: This twelve-position switch selects from
+7 dB to +65 dB of preamplifier gain.
9) Output Level Control: This continuously variable control
provides up to +20 dB additional output gain following the
optional CurveShaper™ EQ circuitry. Fully counter-clockwise -- 0
dB -- indicates unity.
7
To maintain the best performance from your new AEA RPQ503,
take note of these three requirements:
1) Before powering up the unit, make sure the preamp is properly
secured and seated in the slot. Two flat head Phillips screws are
supplied with each preamp.
2) Never place the rack or preamp close to electromagnetic
fields or hot surfaces. Electromagnetic fields created by power
transformers, motors, or RF transmitters can potentially damage or
interfere with the preamp functionality.
3) Before turning on the power, all connections to the preamp
should be made and the Mic Gain and Output Level control set at
their minimum setting. Be sure to examine the signal chain before
powering up the preamp to ensure sudden loud noises are not
emitted which could damage your system or hearing.
