15 WISE-4471 Series User Manual
Chapter 3 Hardware Installation
Figure 3.7 WISE-4471 Wall Mounting
3.2.3 Pole Mounting
For pole mounting, feed the pole mounting ring through the hole in the middle of the
module. The pole mounting ring needs to be unlocked with a screw driver before it can
be inserted through the module. To mount the module on the pole, tightly lock the pole-
mounting ring.
Figure 3.8 WISE-4471 Pole Mounting Installation
