Je bekijkt pagina 18 van 26
SQFlash
CFast 630
Specifications subject to change without notice, contact your sales representatives for the most update information.
REV 1.1 Page 18 of 26 Aug. 10, 2020
12. READ DMA (code: C8h or C9h);
This command reads from “1” to “256” sectors as specified in the Sector Count register using the DMA
data transfer protocol. A sector count of “0” requests “256” sectors transfer. The transfer begins at the
sector specified in the Sector Number register.
13. READ DMA Ext (code: 25h);
This command allows the host to read data using the DMA data transfer protocol.
14. READ MULTIPLE (code: C4h);
This command performs similarly to the READ SECTORS command. Interrupts are not generated on
each sector, but on the transfer of a block which contains the number of sector per block is defined by the
content of word 59 in the IDENTIFY DEVICE response.
15. READ MULTIPLE EXT (code: 29h);
This command performs similarly to the READ SECTORS command. The number of sectors per block is
defined by a successful SET MULTIPLE command. If no successful SET MULTIPLE command has been
issued, the block is defined by the device’s default value for number of sectors per block as defined in
bits (7:0) in word 47 in the IDENTIFY DEVICE information.
16. READ NATIVE MAX ADDRESS (code: F8h);
This command returns the native maximum address. The native maximum address is the highest
address accepted by the device in the factory default condition.
17. READ NATIVE MAX ADDRESS EXT (code: 27h);
This command returns the native maximum address.
18. READ SECTOR(S) (code: 20h or 21h);
This command reads from “1” to “256” sectors as specified in the Sector Count register. A sector count of
“0” requests “256” sectors transfer. The transfer begins at the sector specified in the Sector Number
register.
19. READ SECTOR(S) EXT (code: 24h);
This command reads from “1” to “65536” sectors as specified in the Sector Count register. A sector count
of “0” requests “65536” sectors transfer. The transfer begins at the sector specified in the Sector Number
register.
20. READ VERIFY SECTOR(S) (code: 40h or 41h);
This command is identical to the READ SECTORS command, except that DRQ is never set and no data
is transferred to the host.
21. READ VERIFY SECTOR(S) EXT (code: 42h);
This command is identical to the READ SECTORS command, except that DRQ is never set and no data
is transferred to the host.
22. RECALIBRATE (code: 1Xh);
This command return value is select address mode by the host request.
23. SECURITY DISABLE PASSWORD (code: F6h);
This command transfers 512 bytes of data from the host. Table defines the content of this information. If
the password selected by word 0 match the password previously saved by the device, the device shall
disable the Lock mode. This command shall not change the Master password. The Master password
shall be reactivated when a User password is set.
