SQFlash
CFast 630
Specifications subject to change without notice, contact your sales representatives for the most update information.
REV 1.1 Page 17 of 26 Aug. 10, 2020
F2h
Security Unlock
F3h
Security Erase Prepare
F4h
Security Erase Unit
F5h
Security Freeze Lock
F6h
Security Disable Password
F8h
Read Native Max Address
F9h
Set Max Address
[Command Set Descriptions]
1. CHECK POWER MODE (code: E5h);
This command allow host to determine the current power mode of the device.
2. DOWNLOAD MICROCODE (code: 92h);
This command enable the host to alter the device’s microcode. The data transferred using the
DOWNLOAD MICROCODE command is vendor specific.
All transfers shall be an integer multiple of the sector size. The size of the data transfer is determined by
the content of the LBA Low register and the Sector Count register.
This allows transfer sizes from 0 bytes to 33,553,920 bytes, in 512bytes increments.
3. EXECUTE DEVICE DIAGNOSTIC (code: 90h);
This command performs the internal diagnostic tests implemented by the module.
4. FLUSH CACHE (code: E7h);
This command used by the host to request the device to flush the write cache.
5. FLUSH CACHE EXT (code: EAh);
This command is used by the host to request the device to flush the write cache. If there is data in the
write cache, that data shall be written to the media.
6. IDENTIFY DEVICE (code: ECh);
The IDENTIFY DEVICE command enables the host to receive parameter information from the module.
7. IDLE (code: 97h or E3h);
This command allows the host to place the module in the IDLE mode and also set the Standby timer.
INTRQ may be asserted even through the module may not have fully transitioned to IDLE mode. If the
Sector Count register is non-”0”, then the Standby timer shall be enabled. The value in the Sector Count
register shall be used to determine the time programmed into the Standby timer. If the Sector Count
register is “0” then the Standby timer is disabled.
8. IDLE IMMEDIATE (code: E1h);
This command causes the module to set BSY, enter the Idle (Read) mode, clear BSY and generate an
interrupt.
9. INITIALIZE DEVICE PARAMETERS (code: 91h);
This command enables the host to set the number of sectors per track and the number of heads per
cylinder.
10. NOP (code: 00h);
If this command is issued, the module respond with command aborted.
11. READ BUFFER (code: E4h);
This command enables the host to read the current contents of the module's sector buffer.
