SOM-DB3520 User Manual 16
3.1.6 Jumper, Switch and Button List
Table 3.2: Jumper, Switch and Button List
Label Function
CN2 ATX/AT Mode Selection Pin Header (Default: 1-2 ATX Mode)
CN6
SPI BIOS Boot Selection Pin Header (Default: 2-3 Boot From CPU
Board)
CN18 LVDS Backlight Voltage Selection Pin Header (Default: 1-2 +5V)
CN21&CN22 LVDS Voltage Selection Pin Header (Default: CN21 2-3 +3.3V)
CN19 LVDS or eDP0 HPD Selection Pin Header (Default: 1-2 GND for LVDS)
CN20 LVDS or eDP1 HPD Selection Pin Header (Default: 1-2 GND for LVDS)
CN23
COM1 RS-232 / 485 / 422 Selection Pin Header (Default: 5-6 7-9 8-10
13-15 14-16 RS-232)
CN7 mSATA & Mini PCIE Selection Pin Header (Default: 1-2 Auto Detect)
CN12 Mini PCIE & PCIE x 4 Selection Pin Header (Default: 1-2 Auto Detect)
CN3 RTC Pin Header (Default: 1-2 BAT Connect)
CN16 RS-485 Matched Resistance Selection Pin Header (Default: 2-3Un stuff)
CN17 RS-422 Matched Resistance Selection Pin Header (Default: 2-3Un stuff)
CN4 CAN Matched Resistance Selection Pin Header (Default: 2-3 Un stuff)
USB_SETTING1 USB Setting Configuration Switch (Default: All OFF)
