15 SOM-DB3520 User Manual
Chapter 3 Connectors and Jumper Settings
3.1.5 Connector List
USB_SETTING1 USB Setting Configuration Switch
Pin Function
OFF ON
SW1 USB 2.0 Port 3 Host Mode USB 2.0 Port 3 for MINI PCIE
SW2 USB 2.0 Port 1 Host Mode USB 2.0 Port 1 for OTG Mode
SW3 NC NC
SW4 NC NC
Table 3.1: Connector List
Label Function Label Function
CN13 Q7 Connector DP1 DP Connector
PCIE-4X1 PCIEx4 Connector AUDIO_MIC1 Audio MIC Connector
MINIPCIE1
Mini PCIE or mSATA
Connector
AUDIO_LINEOUT1
Audio Line Out Connec-
tor
JSIM1 SIM Card Connector COM1 COM1 Connector
LVDS1 LVDS Connector COM2 COM2 Box Header
LVDS_INVERTER1
LVDS Inverter Wafer
Box
CAN1 CAN Box Header
SATA1 SATA1 Connector LPC_PH1 LPC Pin Header
SATA2 SATA2 Connector GPIO1 GPIO Pin Header
SATA_PWR1
SATA1 Power Connec-
tor
SYS_FAN1 System FAN Connector
SATA_PWR2
SATA2 Power Connec-
tor
JSPI1 BIOS Socket
SDIO1 SDIO Connector JSPI2 SPI Pin Header
USB_OTG1 USB OTG Connector JI2C1 I2C Wafer Box
USB3_1
USB0 ~ USB1 Connec-
tor
JSMB1 SMBUS Wafer Box
USB2_1
USB2 ~ USB3 Connec-
tor
ATX1 24Pin ATX Connector
USB_PH1
USB4 ~ USB5 Pin
Header
JPS1 4Pin ATX Connector
USB_PH2
USB6 ~ USB7 Pin
Header
JPS2 DCIN Jack
LAN1 LAN Connector
