17 SOM-DB2510 User Manual
Chapter 3 Connectors and Jumper Settings
3.1.8 Jumper, Switch, and Button List
Table 3.2: Jumper, Switch and Button List
Label Function Label Function
BTN3 Sleep Button J14
EDP1/LVDS1 Hot-Plug
Detect Selection Header
BTN1 Power Button J56
Standby Voltage Control
Header
BTN2 Reset Button J44
Module +3.3V/+5V
Power Selection Header
SW4 BOOT SELECT Switch PSON1
AT/ATX Selection
Header
LID1 LID Switch SPI_CN1 SPI Header
J30
Enable Battery Low#
Header
CN14
For CAN Bus port0 Ter-
minal Resistor
M2E_DISABLE_N1 M.2 Wireless Disable CN15
For CAN Bus port1 Ter-
minal Resistor
J29
SMB Alert Enable
Header
J3/J4 DP0 EQ0 Selection
CN9 Header For GPIO Test J5/J6 DP0 EQ1 Selection
J7/J8
LVDS0 Power Selection
Header
J58
PCIE_B_CKREQ#
Selection
J11/J12
LVDS1 Power Selection
Header
J59
PCIE_A_CKREQ#
Selection
J9
LVDS0 Inverter Power
Selection Header
GPIO_0
GPIO0/CAM0_PWR#
Selection
J10
EDP0/LVDS0 Hot-Plug
Detect Selection Header
GPIO_1
GPIO1/CAM1_PWR#
Selection
J26
HDA/I2S Selection
Header
GPIO_2
GPIO2/CAM0_RST#
Selection
J1 DP1/HDMI1 Select GPIO_3
GPIO3/CAM1_RST#
Selection
J13
LVDS1 Inverter Power
Selection Header
GPIO_4
GPIO4/HDA_RST#
Selection
J31 Clear CMOS Header GPIO_5
GPIO5/PWM_OUT
Selection
J25 SPI Power Header GPIO_6
GPIO6/TACHIN Selec-
tion
SW1 COM1 mode Select SATA_ACT_PH1 SATA act# Header
SW2 COM3 mode Select PWRBTN_PH1 Power button Header
J41
Core Power Voltage
Control Header
SYS_RESET_PH1 Reset button Header
J2
DDI1 AUX/DDC Selec-
tion
