SOM-DB2510 User Manual 16
3.1.7 Connector List
Table 3.1: Connector List
Label Function Label Function
ATX1 ATX Connector FAN1 Smart Fan Connector
SMARC_IN1
Wide Range Input
Power Connector
(3V~5.25V)
FAN2 System Fan Connector
DCIN1 DCIN connector CAN0_1 CAN Bus Connector
DP0_HDMI DP & HDMI Connector USB0 USB OTG Connector
USB12
USB 2.0 port1~2 & USB
3.0 port0 Connector
COM1_3
COM Port Port1,3 Con-
nector
TYPEC_DP1 Type-C Connector COM2_4
COM Port Port2,4 Con-
nector
LAN0_LAN1
LAN0 & LAN1 Connec-
tor
CN8
I2C connector for
I2C_PM
LOUT1 Line Out Connector CN7
I2C Connector for
I2C_GP
MIC1 MIC Connector CN10 eSPI Pin Header
CN1_MXM1 SMARC Connector SATAP1 SATA Power Connector
PCIEA-X4 PCIe p24-x4 Connector CSI0_B2B
MIPI B2B Connector for
2M Camera
SATA1 SATA Port0 Connector CSI1_B2B
MIPI B2B Connector for
8M & 13M Camera
PCIED-X1 PCIe p24-x1 Connector SPI_BIOS1
Carrier Board BIOS
Socket (SOIC)
M2 M.2 Key-E Connector BAT1 Coin battery holder
MPCIE_C Mini PCIe Connector BAT2 Smart battery Connector
SIM SIM card Connector LINEOUT_1
I2S Headphone Con-
nector
LVDS1 LVDS1 Connector MIC_1 I2S MIC In Connector
LVDS0 LVDS0 Connector CSI1_FPC
MIPI FPC Connector for
8M & 13M Camera
LVDS1_INVERTER
LVDS1 Invertor Connec-
tor
CSI0_FPC
MIPI FPC Connector for
2M Camera
LVDS0_INVERTER
LVDS0 Invertor Connec-
tor
CN5 I2S2 Connector
SPI_BIOS2
Carrier Board BIOS
Socket (QFN)
CN17 I2S0 Connector
SD SD Card Connector
