5 SOM-A350 User Manual
Chapter 1 General Information
PCI Express
PCI Express: By default, supports 8 PCIe lanes with additional 4 lanes avail-
able, compliant with PCIe Gen 4 (16.0 GT/s) specifications. These lanes can be
bifurcate into PCIe x4, x2, and p17-x1 configurations. For more information, please
reach out to Advantech sales or FAE.
1.3.7 Serial Bus
SMBus
Supports SMBus 2.0 specifications.
I
2
C Bus
Supports I²C bus 7-bit and 10-bit address modes. Support standard mode up to
100 Kb/s, fast mode up to 400 Kb/s.
1.3.8 I/O
Gigabit Ethernet
Ethernet: Intel® I226 Gigabit LAN supports 10/100/1000 Mbps & 2.5 Gbps
Speed.
SATA
Supports 2x ports SATA Gen3 (6.0 Gb/s), backward compliant to SATA Gen2
(3.0 Gb/s) and Gen1 (1.5 Gb/s). The maximum data rate is 600 MB/s. Supports
AHCI 1.3.1 mode (does not support IDE mode).
USB 3.2/USB 2.0
S
upports 2x USB 3.2 Gen2x1 (10 Gbps) ports and 8x USB 2.0 (480 Mbps)
ports
which
are
reverse compatible to USB1.x. For USB 3.2, product supports
LPM (U0, U1, U2, and U3) for power efficiency.
Notice: To meet USB 3.2 Gen2x1 performance, Advantech strongly
recommends using a certificated cable.
USB 2.0
SPI Bus
Supports BIOS flash only. SPI clock can be 14MHz, with capacity up to 256Mb.
GPIO
12 programmable general purpose input/output (GPIO).
Watchdog Timer
Supports multi-level watchdog time-out output. Provides 1-65535 level, from a
100ms to 109.22 minute intervals.
Serial Port
2 x 2-wire serial port (Tx/Rx) supports 16550 UART compliance.
– Programmable FIFO or character mode
– 16-byte FIFO buffer on transmitter and receiver in FIFO mode
– Programmable serial-interface characteristics: 5, 6, 7, or 8-bit character
Table 1.5: PCI Express
Client Type Primary J1
PCIe Lane P0 P1 P2 P3 P4 P5 P6 P7 P8
P9 P10 P11
Default x4 x4
N/A
Option x4 x4 x4
Table 1.6: USB 2.0
Client Type
P0 P1 P2 P3 P4 P5 P6 P7
SoC P0 P1 P2 P3 P4 P5 P6 P7
J1
OC_01
OC_23
OC_45
OC_67
SoC USB_OC#
OC_0
OC_1
OC_1 OC_3
N/A
N/A N/A
