9 SOM-7569 User Manual
Chapter 1 General Information
USB 2.0
SPI Bus
Supports BIOS flash only. SPI clock can be 50MHz, 33MHz, or 20MHz, capacity
up to 16MB.
Watchdog
Supports multi-level watchdog time-out output. Provides 1-65535 levels, from
100ms to 109.22 minutes interval.
Serial port
2 x ports 2-wire serial port (Tx/Rx) supports16550 UART compliance.
– Programmable FIFO or character mode
– 16-byte FIFO buffer on transmitter and receiver in FIFO mode
– Programmable serial-interface characteristics: 5, 6, 7, or 8-bit character
– Even, odd, or no parity bit selectable
– 1, 1.5, or 2 stop bit selectable
– Baud rate up to 115.2K
BIOS
BIOS chip is on module by default. Allows users to place BIOS chip on carrier
board with appropriate design and a pull-down to GND on BIOS_DISABLE# pin.
Power Management
Power Supply
Supports both ATX and AT power modes. VSB is for suspend power and can be
optional if not required (suspend-to-RAM). RTC Battery may be optional if time/
date is not required.
VCC: 5V +/- 5%
VSB: 5V +/- 5% (Suspend power)
RTC Battery Power: 2.0V ~ 3.3V
PWROK
Power OK from main power supply. A high value indicates that the power is
good. This signal can be used to hold off Module startup to allow Carrier based
FPGAs or other configurable devices time to be programmed.
Power Sequence
According to PICMG COM Express COM.0 R 2.1 specification.
Wake Event
Various wake-up event support allows the user to apply to different scenarios.
– Wake-on-LAN(WOL): Wake to S0 from S3/S4/S5
– USB Wake: Wake to S0 from S3
– PCIe Device Wake: depends on user inquiry and may need customized BIOS
LPC Wake: depends on user inquiry and may need customized BIOS
P0 P1 P2 P3 P4 P5 P6 P7
SoC P0 P1 P2 P3 P4 P5 P6 P7
Schematics USB_0_1_OC# USB_2_3_OC# USB_4_5_OC# USB_6_7_OC#
SoC USB_OC# USB_OC0# USB_OC1#
Note! If system CMOS is cleared, we strongly suggest to go to BIOS setup
menu and load default setting at first time of boot up.
