SOM-7569 User Manual 8
Multiple-Display
Expansion Interface
PCIe x1
Intel natively integrates 4 x PCI Express p20-x1 lanes.
HD Audio Interface
Supports Intel HD Audio interface integrated in Intel SoC.
LPC
Supports Low Pin Count (LPC) 1.1 specifications, without DMA or bus master-
ing. Allows connection to Super I/O, embedded controller, or TPM. LPC clock is
25MHz.
Serial Bus
SMBus
Supports SMBus 2.0 specification with Alert pin.
I2C Bus
Supports I2C bus 8-bit and 10-bit address modes, at both 100KHz and 400KHz.
I/O
Gigabit Ethernet
On-module Intel i210IT/i210AT supports IEEE802.3 for 1000BASE-T, 100BASE-
TX, and 10BASE-T (802.3, 802.3u, and 802.3ab). Supports IPv4, IPv6, TCP/
UDP, SCTP, ARP, Neighbor Discovery, EUI-64.
SATA
Supports 2 x ports SATA Gen3 (6.0 Gb/s), backward compliant to SATA Gen2
(3.0 Gb/s) and Gen1 (1.5 Gb/s). Maximum data rate is 600 MB/s. Supports
AHCI 1.3.1 mode (not support IDE mode).
USB 3.0/USB 2.0
2 x ports USB 3.0 (5.0 Gbps) and 8 x ports USB 2.0 (480 Mbps) which are back-
ward compatible to USB 1.x. For USB 3.0, supports LPM (U0, U1, U2, and U3)
manageability to saving power.
USB 3.0
Table 1.6: Multiple-Display
Single Display Dual Display
LVDS, eDP, DP/ HDMI/DVI LVDS+DP/HDMI/DVI eDP+DP/HDMI/DVI
eDP LVDS Single channel 18/24-bit, up
to 1366 x 768
Single channel 18/24-
bit, up to 1366 x 768
-
eDP 3840x2160 @60Hz - 3840x2160 @60Hz
DDI0 DP Up to 4096×2160 @60Hz
or
Up to 3840x2160 @30Hz
Up to 4096×2160 @60Hz
or
Up to 3840x2160 @30Hz
HDMI
DVI 1920 x 1080@60Hz 1920 x 1080@60Hz
PCIe P0 PCIe P1 PCIe P2 PCIe P3 LAN
Default x1 x1 x1 x1 Yes
Option x4 Yes
P0 P1
SoC P0 P1
Schematics USB_0_1_OC#
SoC USB_OC# USB_OC0#
