7 SOM-6832 User Manual
Chapter 1 General Information
1.3.7 Serial Bus
1.3.7.1 SMBus
Support SMBus 2.0 specifications.
1.3.7.2 I
2
C Bus
Supports I²C bus 7-bit and 10-bit address modes. Supports standard mode up to 100
Kb/s & fast mode up to 400 Kb/s.
1.3.8 I/O
1.3.8.1 Gigabit Ethernet
Ethernet: Maxlinear GPY215 Gigabit LAN supports 10/100/1000 Mbps & 2.5
Gbps Speed.
1.3.8.2 SATA
Supports 4 x ports SATA Gen3 (6.0 Gb/s), backward compliant to SATA Gen2 (3.0
Gb/s) and Gen1 (1.5 Gb/s). The maximum data rate is 600 MB/s. Supports AHCI
1.3.1 mode (does not support IDE mode).
1.3.8.3 USB 3.2 /USB 2.0
COM-Express supports USB 3.0. SOM-6832 supports 2 x by default & 2 x via
optional USB 3.2 Gen 2 (10 Gbps) ports, 2 x by optional USB 3.2 Gen2 ports are
shared with PCIe. And 8 x USB 2.0 (480 Mbps) ports are reverse compatible to
USB1.x. The solution supports USB 3.2 via LPM (U0, U1, U2, and U3) for power effi-
ciency.
Notice: Advantech strongly recommends using a certified cable to maximize USB
3.2 Gen 2 performance,.
1.3.8.4 USB 3.2
1.3.8.5 USB 2.0
1.3.8.6 SPI Bus
Supports BIOS flash only. SPI clock is set to 20MHz, with capacity of up to 128Mb.
1.3.8.7 GPIO
8 x programmable general purpose input or output (GPIO).
Type 6 P0 P1 P2 P3
SoC P0 P1 P2 P3
Type 6 OC_01 OC_23
SoC USB_OC# OC_0 OC_2
Type 6 P0 P1 P2 P3 P4 P5 P6 P7
SoC P0 P1 P2 P3 P4 P5 P6 P7
Type 6 OC_01 OC_23 OC_45 OC_67
SoC USB_OC# OC_0 OC_3 OC_3 OC_1
