SOM-6832 User Manual 6
1.3.3 Processor System
1.3.4 Memory
There are a total of 2 x memory sockets on SOM-6832. These support max 32GB
capacity (IBECC supported via Specific CPU SKUs) with 260pin SO-DIMM sockets
(dual-channel).
1.3.5 Graphics/Audio
Graphics Core: Intel
®
Gen10 UHD/P630 Graphic supports DX12, OGL5.0, OCL2.1,
and MPEG2, HEVC/H265, VC1/WMV9 HW decode/encode/transcode acceleration.
1.3.6 Expansion Interfaces
1.3.6.1 PCIe p16-x1
PCI Express x1: Supports default 8 x ports PCIe p16-x1 compliant to PCIe Gen3 (8.0 GT/
s) specifications, configurable to PCIe x4 or PCIe x2. Several configurable combina-
tions may need BIOS modification. Please contact the Advantech sales or FAE for
more details.
1.3.6.2 LPC
Supports Low Pin Count (LPC) 1.1 specifications, without DMA or bus mastering.
Enables connection to Super I/O, embedded controller, or TPM. 25MHz LPC clock.
CPU Std. Freq. Max. Turbo Freq. Core Cache (MB) TDP(W)
Pentium J6426 2.0 GHz 3.0 GHz 4 4 10W
Atom x6413E 1.5 GHz 3.0 GHz 4 4 9W
Atom x6425E 2.0 GHz 3.0 GHz 4 4 12W
Atom x6414RE 1.5 GHz - 4 4 9W
Atom x6425RE 1.9 GHz - 4 4 12W
CPU Graphic Core Base Freq. Max Freq.
Pentium J6426 Gen10 UHD Graphic 400 850
Atom x6413E Gen10 UHD Graphic 500 750
Atom x6425E Gen10 UHD Graphic 500 750
Atom x6414RE Gen10 UHD Graphic 400 -
Atom x6425RE Gen10 UHD Graphic 400 -
Type 6
Row A,B Row C,D
P0 P1 P2 P3 P4 P5 P6 P7
Default
Config
X1 X1 X1 X1 X1 X1 X1 X1
Option 1 X2 X1 X1 X2 X1 X1
Option 2 X2 X2 X2 X2
Option 3 X4 X4
