7 SOM-5899Refresh User Manual
Chapter 1 General Information
1.3.7 Serial Bus
1.3.7.1 SMBus
Supports SMBus 2.0 specification with Alert pin.
1.3.7.2 I²C Bus
Supports I²C bus 8-bit and 10-bit address modes, at both 100KHz and 400KHz.
1.3.8 I/O
1.3.8.1 Gigabit Ethernet
Ethernet: Intel® I219LM Gigabit LAN supports 10/100/1000 Mbps Speed.
1.3.8.2 SATA
Supports 2 ports SATA Gen3 (6.0 Gb/s), backward compliant to SATA Gen2 (3.0 Gb/
s) and Gen1 (1.5 Gb/s). The maximum data rate is 600 MB/s. Supports AHCI 1.3.1
mode (does not support IDE mode).
1.3.8.3 USB 3.0 (3.1)/USB 2.0
COM-Express supports USB 3.0 but SOM-5899Refresh supports 4 USB 3.1 Gen2
(10 Gbps) ports and 4 USB 2.0 (480 Mbps) ports which are reverse compatible to
USB1.x. For USB 3.1, product supports LPM (U0, U1, U2, and U3) for power effi-
ciency.
Notice: To meet USB 3.1 Gen2 performance, Advantech strongly recommends using
a certificated cable.
1.3.8.4 USB 3.0
1.3.8.5 USB 2.0
1.3.8.6 SPI Bus
Supports BIOS flash only. SPI clock can be 50MHz, 33MHz, or 20MHz, with capacity
up to 16MB.
1.3.8.7 GPIO
8 programmable general purpose input or output (GPIO).
1.3.8.8 Watchdog Timer
Supports multi-level watchdog time-out output. Provides 1-65535 level, from a 100ms
to 109.22 minute intervals.
Type 6 P0 P1 P2 P3
SoC P0 P1 P2 P3
Type 6 OC_01 OC_23
SoC USB_OC# OC_0 OC_2
Type 6 P0 P1 P2 P3
SoC P0 P1 P2 P3
Type 6 OC_01 OC_23
SoC USB_OC# OC_0 OC_2
