SOM-5899Refresh User Manual 6
1.3.3 Processor System
1.3.4 Memory
There are a total of 3 memory sockets on SOM-5899Refresh, supporting a 96GB
capacity (utilizing ECC memory modules with specific SKU), 2 DDR4 260pin SOD-
IMM sockets, different channels on the front side (dual-channel), and 1 socket DDR4
SODIMM on the reverse side.
1.3.5 Graphics/Audio
Graphics Core: 9th gen Intel® HD/P630 Graphics Core supports DX12, OGL5.0,
OCL2.1, and MPEG2, HEVC/H265, VC1/WMV9 HW decode/encode/transcode
acceleration.
1.3.6 Expansion Interface
1.3.6.1 PCIe x1
PCI Express x1: Supports default 8 ports PCIe x1 compliant to PCIe Gen3 (8.0 GT/s)
specifications, configurable to PCIe x4 or PCIe x2. Several configurable combina-
tions may need BIOS modification. Please contact the Advantech sales or FAE for
more details.
1.3.6.2 LPC
Supports Low Pin Count (LPC) 1.1 specification, without DMA or bus mastering.
Enables connection to Super I/O, embedded controller, or TPM. 25MHz LPC clock.
CPU Std. Freq. Max. Turbo Freq. Core Cache (MB) CPU TDP
E-2276ME 2.8 4.5GHz 6 12 45W
E-2276ML 2 4.2GHz 6 12 25W
I7-9850HE 2.7 4.4GHz 6 9 45W
I7-9850HL 1.9 4.1GHz 6 9 25W
I3-9100HL 1.6 2.9GHz 4 6 25W
Celeron G4930E 2.4 2.4GHz 2 2 35W
CPU Graphic Core Base Freq. Max Freq.
E-2276ME Intel® UHD Graphics P630 350MHz 1.15GHz
E-2276ML Intel® UHD Graphics P630 350MHz 1.15GHz
I7-9850HE Intel® UHD Graphics 630 350MHz 1.15GHz
I7-9850HL Intel® UHD Graphics 630 350MHz 1.15GHz
I3-9100HL Intel® UHD Graphics 630 350MHz 1.10GHz
Celeron G4930E Intel® UHD Graphics 610 350MHz 1.05GHz
Type 6
Row A,B Row C,D
P0 P1 P2 P3 P4 P5 P6 P7
Default
Config.
X1 X1 X1 X1 X1 X1 X1 X1
Option 1 X1 X1 X2 X1 X1 X2
Option 2 X2 X2 X2 X2
Option 3 X4 X4
