SOM-5898 User Manual 8
1.3.8.5 USB2.0
1.3.8.6 SPI Bus
Supports BIOS flash only. SPI clock can be 50MHz, 33MHz, or 20MHz, capacity up
to 16MB.
1.3.8.7 GPIO
8 x programmable general purpose Input or output (GPIO).
1.3.8.8 Watchdog
Supports multi-level watchdog time-out output. Provides 1-65535 levels, from 100ms
to 109.22 minutes intervals.
1.3.8.9 Serial port
2 ports 2-wire serial ports (Tx/Rx) with16550 UART compliance.
– Programmable FIFO or character mode
– 16-byte FIFO buffer on transmitter and receiver in FIFO mode
– Programmable serial-interface characteristics: 5, 6, 7, or 8-bit character
– Even, odd, or no parity bit selectable
– 1, 1.5, or 2 stop bit selectable
– Baud rates up to 115.2K
1.3.8.10 Express Card
Two sets of Express Card control signals including card detection and reset following
PICMG COM Express R2.1 specification.
1.3.8.11 TPM
Supports TPM 2.0 module by default.
1.3.8.12 Smart Fan
Supports 2 x Fan PWM control signals and 2 x tachometer inputs for fan speed
detection. Provides one on module with connector and the other to the carrier board,
both following PICMG COM Express R2.1 specification.
1.3.8.13 BIOS
BIOS chip is on module by default. Also allows the user to place the BIOS chip on the
carrier board with an appropriate design and jumper setting on BIOS_DIS#[1:0].
Type 6 P0 P1 P2 P3
SoC P0 P1 P2 P3
Type 6 OC_01 OC_23
SoC USB_OC# OC_0 OC_2
BIOS_DIS0# BIOS_DIS#1 Boot up destination/function
Open Open Boot from Module’s SPI BIOS
Open GND SPI_CS0# to Carrier Board, SPI_CS1# to Module
GND GND SPI_CS0# to Module, SPI_CS1# to Carrier Board
Note! If system COMS is cleared, we strongly suggest to go BIOS setup menu
and load default setting the first time of boot up.
