7 SOM-5898 User Manual
Chapter 1 General Information
1.3.6 Expansion Interface
1.3.6.1 PCIe x1
PCI Express x1: Supports default 8 x PCIe p17-x1 compliant ports Gen3 (8.0 GT/s) spec-
ification, configuratble to PCIe p17-x4 or PCIe x2. Several configurable combinations may
need BIOS modification. Please contact to Advantech sales or FAE for more details.
1.3.6.2 LPC
Supports Low Pin Count (LPC) 1.1 specification, without DMA or bus mastering.
Allow to connect Super I/O, embedded controller, or TPM. LPC clock is 25MHz.
1.3.7 Serial Bus
1.3.7.1 SMBus
Supports SMBus 2.0 specification with Alert pin.
1.3.7.2 I2C Bus
Supports I2C bus 8-bit and 10-bit address modes, at both 100KHz and 400KHz.
1.3.8 I/O
1.3.8.1 Gigabit Ethernet
Ethernet: Intel I219LM Gigabit LAN supports 10/100/1000 Mbps Speed.
1.3.8.2 SATA
Supports 4 x ports SATA Gen3 (6.0 Gb/s), backward compliant to SATA Gen2 (3.0
Gb/s) and Gen1 (1.5 Gb/s). Maximum data rate is 600 MB/s. Supports AHCI 1.3
mode.
1.3.8.3 USB3.0/USB2.0
4 x ports USB3.0 (5.0 Gbps) and 4 x ports USB2.0 (480 Mbps) which are backward
compatible to USB1x. For USB3.0, supports LPM (U0, U1, U2, and U3) to save
power.
1.3.8.4 USB3.0
Type 6
Row A,B Row C,D
P0 P1 P2 P3 P4 P5 P6 P7
Default
Config.
X1 X1 X1 X1 X1 X1 X1 X1
Option 1 X1 X1 X2 X1 X1 X2
Option 2 X2 X2 X2 X2
Option 3 X4 X4
Type 6 P0 P1 P2 P3
SoC P0 P1 P2 P3
Type 6 OC_01 OC_23
SoC USB_OC# OC_0 OC_2
