3 SOM-5893 User Manual
Chapter 1 General Information
1.2.3 Display
Graphics Core: AMD Radeon HD9000 GPU supports DX11.1, OpenCL 1.2,
OpenGL 4.2, and H.264 and MPEG4 decoding.
VGA: Up to 1920 x 2000 resolution
LVDS: Supports single and dual-channel 18/24-bit LVDS, up to 1920 x 1200
DDIs (HDMI/DVI/DP): Supports 3 ports HDMI, DVI, or DP multiplexed.
Resolution:
– HDMI 1.4. supports up to 4096 x 2160 @ 30Hz, or 1920 x 1200 @ 60Hz
– DisplayPort 1.2. supports up to 4096 x 2160 @ 30Hz
– DVI Single-Link 1920 x 1200 @ 60Hz
Display Boot Up Order:
– First: LVDS (always first priority by default)
– Second: DDIs
– Third: VGA
Dual Displays: (in DOS/BIOS mode)
– LVDS + any DDI
– LVDS + VGA
– Any DDI + VGA (after LVDS function is disabled)
Triple Displays: (after booting to OS)
– LVDS + any 1 DDI + VGA
– LVDS + any 2 DDIs
– Any 2 DDIs + VGA (after LVDS function is disabled)
– Any 3 DDIs (after LVDS function is disabled)
Quad Displays: (after booting to OS)
– LVDS + any 2 DDIs + VGA
– LVDS + any 3 DDIs
– Any 3 DDIs + VGA (after LVDS function is disabled)
1.2.4 Expansion Interface
PCI Express x16: Supports one PCIe x16 port (default) compliant to PCIe
Gen3* (8.0 GT/s) specifications.Other combinations can be configured using the
BIOS Setup utility. Please contact Advantech’s sales team for more information.
CPU Graphics Core Base Freq. Boost Freq.
RX-427BB 8 600MHz 686MHz
RX-425BB 6 576MHz 654MHz
RX-225FB 3 494MHz 533MHz
x16x8x4DDI
Default 1000
Option 1 0 2 0 0
Option 2 0 1 1 1
Note! PCIe x16 can be reconfigured to 1 DDI + PCIe p9-x8 + PCIe p9-x4 without
hardware modifications.
