SOM-5893 User Manual 4
PCI Express x1: Supports seven PCIe p10-x1 ports (default) compliant to PCIe
Gen2* (5.0 GT/s) specifications. Other combinations can be configured using
the BIOS Setup utility. Please contact Advantech’s sales team for more details.
Audio Interface: HD audio interface
LPC Bus
SMBus
I2C Bus: Up to 400KHz
SPI: Supports SPI BIOS only
1.2.5 I/O
Ethernet: Intel i211AT Gigabit LAN supports speeds of 10/100/1000 Mbps
SATA: Four SATA Gen3 (600 Gb/s) ports
USB Interface: Four USB3.0 and eight USB 2.0 ports
Serial Port: Two 2-wire serial ports
Express Card: Two ports
Panel Control: Supports panel backlight on/off and brightness control
Thermal Protection: Supports thermal shutdown and APU throttling
Watchdog Timer: Multi-level, multi-option watchdog timer with 65536-level
timer interval (0 ~ 65535 seconds)
Smart Fan: One port on module, one port on carrier board
GPIO: 8-bit GPIO
Hardware Monitor: Vin, 5VSB, CMOS
TPM: BOM option, default not available
1.2.6 iManager 2.0
Refer to Section 4.3.
1.2.7 Mechanical and Environmental Specifications
Dimensions: 125 x 95 mm (4.92 x 3.74")
Power Type and Supply Voltage:
– ATX: +8.5~20 V and +4.75~5.25VSB (standby power)
– AT: +8.5~20 V
– CMOS Battery: +3.3 V
Power Requirement:
– Test Condition: SOM-5893RG-U7A1E (RX-427BB), DDR3L-1600 16GB,
WIN7 64-bit, under 12V and 5VSB input power supply.
– Idle: 16.6W
– Max: 35.8W (Burn-in V7.0 Pro)
Temperature Specifications:
– Operating: 0 ~ 60
C (32 ~ 140 F)
– Storage: -40 ~ 85
C (-40 ~ 185 F)
Humidity Specifications:
– Operating: 40
C @ 95% relative humidity, non-condensing
– Storage: 60
C @ 95%relative humidity, non-condensing
x4 x2 x1
Default 0 0 7
Option 1 0 2 3
Option 2 1 0 3
