3 RSB-4810 User Manual
Chapter 1 General Introduction
1.1.2 Mechanical Specifications
Dimensions: 146 x 102 mm/5.74 x 4.01 in
Height: 20 mm/0.78 in
Reference Weight: 200 g; 0.44 lb
1.1.3 Electrical Specifications
Power Supply Type: DC-in 12V
RTC Battery:
– Typical voltage: 3V
– Normal discharge capacity: 210mAH
I/O
SATA 1 x SATA 3.0
SATA Power 1
USB
1 x USB 3.2 Gen 1 by 1 Type A
1 x USB 3.2 Gen 1 by 1 Type A/OTG
2 x USB 2.0 Pin header
Audio 1 x Mic in, HP, and Speaker out via pin header
Serial Port
1 x RS-232 w/2wire via DB9;
2 x RS-232/RS-485 by pin header;(SW config)
3 x RS-232 by pin header;
1 x Debug by pin header
SPI -
CAN 2 x CAN FD
GPIO 6 x GPIO via pin header (3.3V TTL level)
I2C 1 x can be configured to GPIO via software
Button 1 x Reset button
Indicator LED
1 x Power LED
1 x HDD LED
Expansion
Mini-PCIe 1 x Mini PCIe slot, w/USB 2.0 and 1 x PCIe 3.0
M.2
1 x M.2 2230 Key E slot, w/SIDO*UART*PCIe 3.0 x1,
and 1 x USB 2.0
SD 1 x Micro SD
SIM 1 x Nano SIM
Power
Power Supply
Voltage
12V
Power Type DC-in
Power
Consumption
Boost 13.1W@12V
Environment
Operating
Temperature
0 ~ 60 °C/32 ~ 140 °F
-40 ~ 85 °C/-40 ~ 185 °F
Operating Humidity 5 ~ 95% Relative Humidity, non-condensing
Mechanical
Dimensions
(W x D x H)
146 x 102 x 20 mm/5.74 x 4.01 x 0.78 in
Operating System Linux Debian, Android
Certifications CE/FCC Class B
