RSB-4810 User Manual 2
1.1 Introduction
Advantech’s RSB-4810 is an Arm-based 3.5" single board computer (SBC) powered
by Rockchip RK3568 SOC. It leverages 4 x Arm Cortex-A55 cores, a 1.0TOPs NPU,
and a Mali-G52 graphics engine. RSB-4810 provides USB 3.0, PCIE 3.0, SATA 3.0, 2
x Gigabit Ethernet ports, a single channel LVDS (shared with MIPI-DSI), 6 x UART,
and 2 x CAN FD for embedded applications. RSB-4810 also features Mini-PCIe, M.2
E-Key, and SIM card slot for Wi-Fi 6/BT, 5G/LTE, and AI acceleration modules. These
features make Advantech’s RSB-4810 an ideal solution for entry level edge AI com-
puting in AIoT applications.
1.1.1 Product Features
Specifications RSB-4810
Form Factor 3.5” SBC
Processor
CPU
Rockchip RK3568/RK3568J Arm Quad Cortex-A55, up
to 2.0GHz
NPU Up to 1.0 Tops
Memory
Technology LPDDR4
Capacity Onboard 2/4GB
Flash 16/32GB eMMC NAND Flash for OS
Display
LVDS 1 x single channel LVDS(Default)or 1 x 4Lane MIPI-DSI
HDMI 1 x HDMI 2.0, up to 4096x2304@60fps
VGA -
eDP 1, max 2.7Gbps
Graphics Engine
Mali-G52 support OpenGL ES 1.1/2.0/3.2, Vulkan 1.0/
1.1, OpenCL 2.0
H/W Video Codec
Decoder: H.265 HEVC/MVC Main10/H.264 AVC/MVC
Main10/VP9 Profile0/2 up to 4096x2304@60fps;
VP8,VC1,MPEG-4/2/1, up to 1920x1088@60fps
Encoder: H.264/AVC H.265/HEVC MP@level4.1, up to
1920x1080@100fps. Support YUV/RGB video source
with rotation and mirror
Video In MIPI CSI -
Ethernet
Chipset RTL8211FS
Speed 2 10/100/1000 Mbps
Watchdog Timer 0 ~ 60s, default 60s
