RSB-4410 User Manual 12
2.2.2.8 Audio Phone Jack(CN9)
RSB-4410 offers Line-out stereo speakers, earphone can be connected to the line
out jack.
Figure 2.7 Audio Phone Jack
2.2.2.9 DC power Jack (CN10)
RSB-4410 comes with a DC-Jack header that carries 12V DC external power input.
Figure 2.8 DC Power Jack
2.2.2.10 HDMI (CN11)
RSB-4410 provides one HDMI interface connector which provides all digital audio/
video interfaces to transmit the uncompressed audio/video signals and is HDCP and
CEC compliant Connect the HDMI audio/video device to this port. HDMI technology
can support a maximum resolution of 1920 x 1080p but the actual resolutions sup-
ported depends on the monitor being used.
Pin Description
1 GND
2 LINEOUT_L
3
4 LINEOUT_R
5 GND
Pin Description
1 DC_IN
2 GND
Pin Description
1 HDMI_TD2+
2 GND
3 HDMI_TD2-
4 HDMI_TD1+
5 GND
6 HDMI_TD1-
7 HDMI_TD0+
8 GND
9 HDMI_TD0-
10 HDMI_CLK+
11 GND
