RSB-4220 User Manual 44
3.7.2 Service Configuration
RSB-4220 is equipped to support the following five common network services: TFPT,
FTP, SSH, Telnet, and HTTP.
3.7.2.1 TFTP Server
Upon booting up RSB-4220, TFTP service will be initiated by default. The working
directory for the TFTP server is /tftpboot. Users must execute “chmod 777 /tftpboot”
on RSB-4220 to enable operation of the TFTP server. Then, users can communicate
with RSB-4220 by TFTP via the TFTP client on the host PC. Use the command line
to obtain and store files as follows:
You can also input the following commands on RSB-4220 to transmit files to the
remote device:
This command can be used to download file1 under tftp path of the target device to
the current path of RSB-4220. "TARGET_SYSTEM_IP" is IP address of the target
device.
This command can be used to upload file2 under the current path of RSB-4220 to tftp
path of the target device. "TARGET_SYSTEM_IP" is IP address of the target device.
The service start command is as follows:
The service stop command is as follows:
hostPC$ tftp TARGET_SYSTEM_IP
tftp>get file1
tftp>put file2
Note! The command “get file1” is for downloading File 1 from the TFTP server.
File 1 exists in the /tftpboot directory on RSB-4220.
The command “put file2” is for uploading File 2 to the TFTP server. If
File 2 is uploaded successfully, File 2 will be saved to the /tftpboot direc-
tory on RSB-4220.
root@am335x-adv:~# tftp -g -r file1 TARGET_SYSTEM_IP
root@am335x-adv:~# tftp -p -l file2 TARGET_SYSTEM_IP
root@am335x-adv:/ # /etc/init.d/tftpd start
root@am335x-adv:/ # /etc/init.d/tftpd stop
