RSB-3710 User Manual 12
2.3.2.4 LVDS Connector (LVDS)
RSB-3710 features an LVDS 20x2-pin board-to-board connector for one port single
channel 24 bit LVDS or one port dual channel 24 bit LVDS. To avoid damage to LCD
panel when connecting to an LVDS, please ensure the correct voltage level has been
set before powering the device on (refer to jumper setting description for the BL and/
or LCD datasheet used in the target application)
Pin Description
1 VDD_LVDS
2 VDD_LVDS
3 GND
4 GND
5 VDD_LVDS
6 VDD_LVDS
7 LVDS1_Z_D0N
8 LVDS2_Z_D0N
9 LVDS1_Z_D0P
10 LVDS2_Z_D0P
11 GND
12 GND
13 LVDS1_Z_D1N
14 LVDS2_Z_D1N
15 LVDS1_Z_D1P
16 LVDS2_Z_D1P
17 GND
18 GND
19 LVDS1_Z_D2N
20 LVDS2_Z_D2N
21 LVDS1_Z_D2P
22 LVDS2_Z_D2P
23 GND
24 GND
25 LVDS1_Z_CLK0N
26 LVDS2_Z_CLK0N
27 LVDS1_Z_CLK0P
28 LVDS2_Z_CLK0P
29 GND
30 GND
31 NC
32 NC
33 GND
34 EDP_HPD(or LVDS GND)
35 LVDS1_Z_D3N
36 LVDS2_Z_D3N
37 LVDS1_Z_D3P
38 LVDS2_Z_D3P
39 LVDS_PIN39(PD 4.7Kohm to GND)
40 LVDS_CTRL
