ROM-3620 User Manual 10
3.1 Pin Definition
Please refer to the 4 x board-to-board connector pin definition detailed below:
A2 PWR B2 PWR C2 PWR D2 PWR
A4 RSVD B4 N/A C4 N/A D4 RSVD
A6 RSVD B6 N/A C6 N/A D6 RSVD
A8 RSVD B8 N/A C8 PWR D8 RSVD
A10 RSVD B10 N/A C10 N/A D10 RSVD
A12 RSVD B12 N/A C12 N/A D12 RSVD
A14 RSVD B14 N/A C14 PWR D14 RSVD
A16 RSVD B16 N/A C16 N/A D16 RSVD
A18 RSVD B18 N/A C18 N/A D18 RSVD
A20 PWR B20 PWR C20 PWR D20 PWR
A22 RSVD B22 N/A C22 N/A D22 I2C0_DATA
A24 RSVD B24 N/A C24 PWR D24 I2C0_CLK
A26 RSVD B26 N/A C26 N/A D26 I2C1_DATA
A28 RSVD B28 N/A C28 N/A D28 I2C1_CLK
A30 RSVD B30 N/A C30 N/A D30 I2C2_DATA
A32 PWR B32 N/A C32 N/A D32 I2C2_CLK
A34 GBE1_MDI0+ B34 N/A C34 N/A D34 PWR
A36 GBE1_MDI0- B36 N/A C36 PWR D36 CAN0_TX
A38 PWR B38 PWR C38 N/A D38 CAN0_RX
A40 GBE1_MDI1+ B40 N/A C40 N/A D40 CAN1_TX
A42 GBE1_MDI1- B42 N/A C42 PWR D42 CAN1_RX
A44 PWR B44 N/A C44 N/A D44 PWR
A46 GBE1_MDI2+ B46 N/A C46 N/A D46 I2S_BCLK
A48 GBE1_MDI2- B48 N/A C48 PWR D48 I2S_DIN
A50 PWR B50 N/A C50 N/A D50 I2S_DOUT
A52 GBE1_MDI3+ B52 N/A C52 N/A D52 I2S_LRCLK
A54 GBE1_MDI3- B54 N/A C54 PWR D54 I2S_MCLK
A56 PWR B56 PWR C56 N/A D56 PWR
A58
USB1_HOST
_D+
B58 N/A C58 N/A D58 UART0_TX
A60
USB1_HOST
_D-
B60 N/A C60 PCIE_WAKE# D60 UART0_RX
A62 PWR B62 N/A C62 PWR D62 UART0_RTS#
A64 RSVD B64 N/A C64 N/A D64 UART0_CTS#
A66 PWR B66 N/A C66
GBE0_LINK_AC
T#
D66 UART1_TX
A68
FORCE_RE-
COV#
B68 N/A C68 GBE0_LINK100# D68 UART1_RX
A70 PWR B70 N/A C70
GBE0_LINK1000
#
D70 N/A
A72 EMERGY# B72 N/A C72 PWR D72 N/A
A74 PWR B74 N/A C74
USB_OTG_P-
WR_EN
D74 PWR
A76 WAKE# B76 N/A C76 USB_OTG_OC# D76 UART2_TX
A78 SLEEP# B78 PWR C78 USB_OTG_ID D78 UART2_RX
