3 PPC-6121 User Manual
Chapter 1 General Information
1.4 Rear Panel
The PPC-6121 rear panel features four VESA mount (75 x75 mm) holes (see Figure
1.2) for easy mounting.
Figure 1.2 Rear panel
1.5 Panel Underside
The system I/O listed below are located in the underside of the panel (see Figure
1.3).
1 x Line-Out/ Mic-In
2 x Intel Gigabit Ethernet
4 x USB 3.1
1 x DIO
1 x Isolated RS-422/485
1 x VGA
1 x HDMI
4 x RS-232
1 x DC input
1 x Power button
Figure 1.3 Panel underside
