PPC-6121 User Manual 2
1.1 Introduction
Advantech’s PPC-6121 is a 12.1" color TFT LCD panel PC powered by an 8th gen
Intel® Core™ i/Celeron® processor.The PPC-6121 panel PC is designed for high-
performance computing, features diverse I/O, including four RS232, one isolated
RS422/485, dual Gb Ethernet connectors that support Intel® AMT, and one expan-
sion slot, and can support a wide range of applications. Moreover, the user-friendly
interface makes the panel PC an ideal host device for various information-related
operations.
1.2 Key Features
Robust IP65-rated true-flat color TFT LCD
8th generation Intel® Core™ i/Celeron® processor (thermal power design:
35W)
2 x 260-pin SODIMM DDR4 2666 MHz (max. 32 GB)
1 x M.2 2230 (E key)
1 x mSATA bay (supports RAID 0 and 1)
1 x Optional TPM 2.0
1 x Optional PCI/PCIe p12-x4 expansion kit
1 x Isolated RS422/485 (terminal block)
Dual GbE with Intel® AMT12.0 support
Optional mini PCIe 802.11b/g/n wireless module
1.3 Front Panel
The PPC-6121 front panel is a true-flat color TFT LCD resistive touch touchscreen
(see Figure 1.1) with an IP65 rating for dust and water tolerance.
Figure 1.1 Front panel
Aluminium frame
Power status
Touchscreen
LED indicator
