PPC-412 User Manual 12
3. Remove the yellow warning tag first. Then remove the screws as indicated in
the red circle. (See Figure 2.8), and take out the strength plate & CPU heat sink.
Note! Take out the black and blue thermal grease from the accessory box (as
indicated in Figure 2.9). Attach the CPU heat sink and strength plate
after the grease is applied.
Figure 2.8
Figure 2.9
Note! CPU cooler pad surface is isolated by anodization treatment to avoid
static electricity (CPU contact side excluded).
