PPC-315W/318W/321W/324W-TGL User Manual 2
1.1 Introduction
Advantech's PPC-315W/318W/321W/324W TGL is an all-in-one light panel PC with
a wide format 15.6"/18.5"/21.5"/23.8" full HD LCD screen. It is powered by an 11th
Gen Intel
®
Core™ i processor, PPC-315W/318W/321W/324W TGL to provide high
performance, optimal memory, graphics, and peripheral I/O support in a compact,
fanless, embedded system. With a highly durable design, PPC-315W/318W/321W/
324W TGL adopts a flat touchscreen with an IP66-rated front panel in a die-cast alu-
minum alloy enclosure. It is an ideal choice for integration into various applications.
1.2 Key Features
Robust IP66-rated true-flat color TFT LCD
Ultra-thin fanless design with solid aluminum alloy enclosure
11th Gen Intel
®
Core™ i CPU with a fanless design
Dual-channel memory slots, max 64GB
Supports dual displays (1 x external HDMI)
1 x M.2 bay (2242/2280 NVME or SATA Interface) for storage with support for
SATA RAID 0, 1
1 x 2500BASE-T Ethernet supports Time-Sensitive Network (TSN) technology
Supports TPM 2.0 hardware security
Supports Type-C (USB only)
1.3 Front Panel
The PPC-315W/318W/321W/324W TGL front panel is a true-flat color TFT LCD
touchscreen with Projected Capacitive Multi-Touch. The front panel is IP66 rated for
dust and water tolerance (Figure 1.1).
Note: The examples provided in this manual are of the PPC-315W TGL model.
Figure 1.1 Front Panel
Power status LED: Off (S5) Orange; Sleep (S3) Orange; On (S0) Blue.
Touchscreen
Aluminum
Frame
LED Indicator
for Power
