55 Chapter 7
CNT = 0 Latch count of selected counter(s).
STA = 0 Latch status of selected counter(s).
C2, C1 & C0 Select counter for a read-back operation.
C2 = 1 select Counter 2
C1 = 1 select Counter 1
C0 = 1 select Counter 0
If you set both SC1 and SC0 to 1 and STA to 0, the register selected by
C2 to C0 contains a byte which shows the status of the counter. The data
format of the counter read/write register then becomes:
OUT Current status of counter output
NC Null count is 1 when the last count written to the
counter register has been loaded into the counting
element
The pacer enable register, located at address BASE+10, has a close rela-
tionship with the counter operation. Refer to pages 32~33, Pacer Enable
Register, for the register data format. The TC0 bit enables and disables
the pacer. If TC0 is 0, the pacer is enabled. If TC0 is 1, the pacer is dis-
abled.
BASE+12/13/14 - status read-back mode
Bit D7 D6 D5 D4 D3 D2 D1 D0
Value OUTNCRW1RW0M2M1M0BCD
