PCM-3718 Series User Manual 54
RW1 & RW0 Select read/write operation
M2, M1 & M0 Select operating mode
BCD Select binary or BCD counting
If you set the module for binary counting, the count can be any number
from 0 up to 65535. If you set it for BCD (Binary Coded Decimal) count-
ing, the count can be any number from 0 to 9999.
If you set both SC1 and SC0 bits to 1, the counter control register is in
read-back command mode. The control register data format becomes:
Operation RW1 RW0
Counter latch 0 0
Read/write LSB 0 1
Read/write MSB 1 0
Read/write LSB first, then MSB 1 1
M2 M1 M0 Mode Description
0000 Programmable one shot
0011 Programmable one shot
X 1 0 2 Rate generator
X 1 1 3 Square wave rate generator
1004 Software triggered strobe
1015 Hardware triggered strobe
BCD Type
0 Binary counting 16-bits
1 Binary coded decimal (BCD) counting
BASE+15 - 8254 control, read-back mode
Bit D7 D6 D5 D4 D3 D2 D1 D0
Value 1 1 CNTSTAC2C1C0X
