3 Chapter 1
1.3 Specifications
1.3.1 Analog Input
• Channels: 16 single-ended or 8 differential, jumper selectable
• Resolution: 12 bits
• FIFO: 1k (PCM-3718HO only)
• Input Range: (software programmable, VDC)
PCM-3718H and PCM-3718HO
Bipolar: ±10, ±5, ±2.5, ±1.25, ±0.625
Unipolar: 0 ~ 10, 0 ~ 5, 0 ~ 2.5, 0 ~ 1.25
PCM-3718HG
Bipolar: ±10, ±5, ±1, ±0.5, ±0.1, ±0.05, ±0.01, ±0.005
Unipolar: 0 ~ 10, 0 ~ 1, 0 ~ 0.1, 0 ~ 0.01
• Max. Sampling Rate: 100 KHz* (DMA transfer)
*80 kHz on P4-based (or upper) system
* The DMA mode AI sampling can only be operated on the ISA
bus of a P3* motherboard. For platforms that are using P4**
motherboard or above, the DMA mode AI sampling rate of
Advantech’s ISA cards may decrease, or not work at all.
*P3 = Pentium III microprocessor from Intel
**P4 = Pentium IV microprocessor from Intel
We recommend the customer use Intel P3-installed PC to work
with Advantech’s ISA cards for high-speed DMA AI sampling.
• Maximum Data Throughput
PCM-3718H and PCM-3718HO: 100 kHz
PCM-3718HG: (variable, depending on PGIA settling time)
Gain Speed
0.5, 1 100 kHz
5,10 35 kHz
50,100 7 kHz
500,1000 770 Hz
