PCM-3718 Series User Manual 2
Chapter 1 General Information
1.1 Introduction
The PCM-3718 Series consist of high performance multifunction data
acquisition modules that attach to the PC/104 connector on your CPU
card or PC/104 module. It offers 12-bit A/D conversion and digital input/
output.
The automatic channel-scanning circuitry and the onboard SRAM let you
perform multiple channel A/D conversions with DMA and individual
channel gains.
These PC/104 modules are fully software compatible with the popular
PCL-818H and PCL-818HG. This puts rich software support and a wide
variety of external signal conditioning boards at your disposal.
The PCM-3718 Series is excellent for data acquisition, process control,
automatic testing and factory automation.
1.2 Features
• 16 single-ended or 8 differential analog inputs, jumper selectable
• 12-bit A/D converter, up to 100 kHz sampling rate with DMA transfer
• Software programmable gain value for each analog input channel
• Software selectable input range for each analog input channel
• Two 8-bit digital input/output channels, TTL compatible
• Flexible triggering options: software trigger, programmable pacer trig-
ger and external pulse trigger
• Data transfer by program control, interrupt handler routine or DMA
• 1k FIFO on AI (PCM-3718HO)
• 12-bit D/A Converter (PCM-3718HO)
• 16-bit programmable counter/timer
