BitFlow, Inc. • 400 West Cummings Park, Suite 5050 • Woburn, MA 01801 USA • +1-781-932-2900 • www.bitflow.com
Getting Started with the BitFlow SDK 6.6 16
3. Make sure you BIOS is the latest version for your motherboard
4. Check to see if the BIOS has a parameter called “Data Link Feature Exchange”
or “DLFE”. If it does have this options, disable it.
If the synthetic image does not appear in one of the viewing
applications:
Try the board in another PCIe slot.
Remove all PCIe cards except the BitFlow board and your display card.
Try the BitFlow board in another PC.
Try updating the drivers for you display card.
If you get time out errors in one of the viewing applications
with your camera:
Make sure your camera has power.
Check the cable between the camera and the board to ensure all the connec-
tors are tight.
Make sure you have selected the correct configuration file for your camera.
Make sure your camera is set in the mode for which configuration file was
designed.
If you are using an encoder or trigger, make sure that they are sending the
correct signals to the board (see the hardware reference manual for interface
specifications). Confirm that the camera works in free running mode first.
Your system should be at least 20% faster than your camera’s data rate. If you
are unsure of your camera’s data rate use the following formula:
DataRate (MB/S) = CameraTaps × PixelClockFrequency × BytesPerPixel
Where:
CameraTaps = The number of data streams coming out of the camera (usually
correlates with the sensor design).
PixelClockFrequency = The frequency of the data strobe clocking out the
pixel data.
BytesPerPixel = 1 (for monochrome or 8-bit cameras)
BytesPerPixel = 2 (for cameras with 9 to 16-bit pixels)
BytesPerPixel = 3 (for packed (RGB) color cameras)
BytesPerPixel = 4 (For unpacked (ARGB) color cameras)
MB/S = Megabytes per second
The formulas define the maximum possible data rate produced by the camera,
the average data rate may be somewhat slower.
If the video display is blank and you don’t get time out errors in
one of the viewing applications:
Check the lens cap and F-Stop settings.
