PCI-1716_Series User Manual 12
* Not available for PCI-1716L.
Table 2.3: I/O Connector Signal Description
Signal Name Reference Direction Description
AI<0..15> AGND Input Analog input terminals.
Each channel pair (AI0 & AI1, AI2 & AI3,
etc.) can be configured as a differential
input channel or two single-ended chan-
nels.
AO<0..1>_REF* AGND Input Analog output reference voltage input ter-
minals.
AO<0..1>_OUT* AGND Output Analog output terminals.
AGND - - Ground terminals for analog signals.
DI<0..15> DGND Input Digital input terminals.
DO<0..15> DGND Output Digital output terminals.
CNT0_CLK DGND Input Counter 0 clock input terminal.
CNT0_OUT DGND Output Counter 0 output terminal.
CNT0_GATE DGND Input Counter 0 gate input terminal.
ECLK_IN DGND Input External clock input terminal.
It is the external conversion/sample/update
clock source for various functions.
ECLK_OUT DGND Output External clock output terminal.
Analog input conversion clock is routed to
this terminal. It can be used to synchronize
acquisition among multiple devices.
ECLK_GATE DGND Input External clock gate input terminal.
DGND - Ground terminals for digital signals.
+12V DGND Output +12 V supply output.
+5V DGND Output +5 V supply output.
