PCI-1285/1285E User Manual 24
tech.Motion.dll is the .NET motion control library. Common Motion Utility.exe is the
utility which is running now. The fourth and fifth lines are driver files (Kernal-Mode
and User-Mode), which depends on device type; the sixth line is DSP firmware and
the seventh line is FPGA of the hardware.
5.2.2.2 Refresh
This button supports refresh function. Click [Refresh], Device Tree will re-load the
Device. No device is selected by default after operation.
5.2.2.3 Save
This button can save all properties of the axes of the selected device.
5.2.2.4 Load
This button can import configurations of all axes of the selected device. After the
device is selected, click the button, an Open Dialog box will appear. Select the previ-
ously exported configuration file and click [OK], you can import the configuration file
into the Device hardware.
5.2.2.5 Download
For PCI-1285/1285E series, it's DSP-based motion controller. After clicking device,
you can see the interface as follows.
Note! Only DSP-based motion control card will show the DSP and FPGA
information.
