5 PCE-7131/5131/5031 User Manual
Chapter 1 Hardware Configuration
1.4 Jumpers and Connectors
Connectors on the PCE-7131/5131/5031 single host board link it to external devices
such as hard disk drives and a keyboard. In addition, the board has a number of
jumpers used to configure the system for your application.
The tables below list the function of each of the board jumpers and connectors. Later
sections in this chapter give instructions on setting jumpers. Chapter 2 gives instruc-
tions for connecting external devices to your motherboard.
Table 1.1: Jumpers
Label Function
JCMOS1 CMOS clear
JME1 Clear ME data
JWDT1 Watchdog timer output selection
JOBS1 Super I/O Alarm setting
Table 1.2: Connectors
Label Function
USB3C1 USB3 port1
LAN1 Intel I219LM (PCE-7131/5131); Intel I219V (PCE-5031)
LAN2 Intel I210AT (PCE-7131); Intel I211 (PCE-5131/5031)
VGA1 VGA connector
KBMS1 External PS/2 keyboard and mouse connector
KBMS2 Internal PS/2 keyboard and mouse connector
HDAUD1 Advantech HD audio module expansion pin-header
LPC1 LPC module expansion pin-header
Sysfan1 4 PIN fan power connector for supporting PWM or DC fan
LANLED1 LANLED
USB11 USB port 10
USB45 USB port 4, 5
USB3H2 USB3 port 5, 6
USB3H1 USB3 port 3, 4
USB3H3 USB3 port 7, 8
COM1 RS-232 (9-pin Box Header)
COM2 RS-232 (9-pin Box Header)
LPT1 Parallel port
SATA0 / M.2 SATA port 0
SATA 1~5 SATA Port 1 ~ 5
SPI_CN1 CMOS flash jig pin-header
SPI1 CMOS ROM
DP1 Display port pin-header 1
DP2 Display port pin-header 1
JCMOS1 Clear CMOS
JME1 Clear ME
JFP1 + JFP2
Power Switch / Reset connector / External speaker / SATA HDD LED
connector
