3 PCE-3029/4129 User Manual
Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
CPU: LGA1151-socket Core i7/i5/i3, Pentium and Xeon E3-1200v5 series pro-
cessors.
L2 Cache: Please refer to CPU specification for detailed information.
BIOS: AMI SPI BIOS (128 Mb SPI).
System Chipset: Intel C236 (PCE-4129); Intel H110 (PCE-3029).
SATA hard disk drive interface: PCE-3029 supports three SATA 3.0 ports, and
PCE-4129 supports four SATA 3.0 ports.
1.3.2 Memory
RAM:
– PCE-4129: Up to 32 GB in two 260-pin SO-DIMM sockets. Supports dual-
channel DDR4 1866/2133 SDRAM WITH or WITHOUT ECC function.
– PCE-3029: Up to 32 GB in two 260-pin SO-DIMM sockets. Supports dual-
channel DDR4 1866/2133 SDRAM WITHOUT ECC function.
1.3.3 Input/Output
PCIe bus: One PCIe x16 or Two PCIe p13-x8 from CPU and One PCIe p13-x4 from
PCH.
Enhanced parallel port: This EPP/SPP/ECP port can be configured to LPT1 or
disabled. A standard DB-25 female connector provided.
Serial ports: Two RS-232 serial ports
PS/2 keyboard and mouse connector:
One 6-pin mini-DIN connectors is
located on the mounting bracket for easy connection to a PS/2 keyboard and
mouse via the Y-cable included in the package.
USB port: 7 x USB 2.0 (480Mbps) and 3 x USB 3.0 (5Gbps)
LPC: One LPC connector to support optional TPM (PCA-TPM-00A1E), COM-
232 (PCA-COM232-00A1E), COM-422/485 (PCA-COM485-00A1E) modules.
GPIO: Supports 8-bit GPIO from super I/O for general purpose control applica-
tion.
Note! PCE-3029/4129 do NOT support PATA (IDE) interface.
Only PCE-4129 supports Intel Xeon processors.
Note! 1. Due to the inherent limitations of the PC architecture, the system
may not fully detect 16 GB RAM when 16 GB of RAM is installed.
2. A 32-bit OS may not fully detect 4 GB of RAM when 4 GB is
installed.
Please select Intel ECC supported processor to enable ECC function.
