13 PAX-121 User Manual
Chapter 2 Installation
2.2.4 Input/Output Signal Ports
DC POWER Input: +12V Power Connector
DP Input
HDMI Input
HDMI Output
DVI Input
AUDIO Input
AUDIO Output
USB UP
2.2.5 Input/Output Signal Ports
2.3 Viewing Angle
PAX-121 display is compatible with a VESA 100x100mm or 75x75mm mount. When
mounted on a suitable stand the PAX-121 monitor can be vertically adjusted to the
preferred viewing angle for maximum comfort.
2.3.1 Install VESA Mounting
The PAX-121 Series also provides mounting holes to help system integrators conve-
niently integrate the panel PC into their system.
Never use mounting brackets except as provided by Advantech to prevent unreliable
mounting of the PAX-121 Series. VESA mount installation should be carried out by a
professional technician; please contact a service technician or your retailer if you
need this service.
Installation instructions follow:
First attach wall-mounting to the back cover of the PAX-121 Series, then secure it in
place with the four Phillips-head screws provided.
Caution! Do not force the monitor past its maximum extension in any direction as
this may damage the monitor and the monitor stand.
Prudence! Ne forcez pas le moniteur au-delà de son extension maximale dans
aucune direction car cela pourrait endommager le moniteur et son sup-
port.
Note! Please use M4x10L (Maximum) screws and use 4pcs screws for VESA
mounting.
Warning! Be sure to secure the screws of the mounting bracket tightly. A loose
joint between the PAX-121 Series and mounting bracket may create
danger of injury.
