MIC-78M20/M20-01/M11 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 x MIC-78M20/M20-01/M11 i-Module
2. 1 x Startup Manual
3. 2 x Wall mount bracket
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
le. Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe.)
MIC-78M20/M20-01/M11
PCIe Expansion Module for MIC-78 Series
Embedded Systems
Startup Manual
PCIe Slots
• MIC-78M20:
1 x PCIe x16 socket (PCIe x16 signal)
1 x PCIe p1-x4 socket (PCIe p1-x4 signal)
• MIC-78M20-01:
2 x PCIe x16 socket (PCIe x8 signal)
1 x PCIe p1-x4 socket (PCIe p1-x4 signal)
• MIC-78M11:
1 x PCIe x16 socket (PCIe x16 signal)
1 x PCI socket
Note 1: PCIe x16 supports up to 75W power consumption.
Note 2: PCIe p1-x4 supports up to 25W power consumption.
Note 3: MIC-78M20 does not support MIC-770 series
systems.
Note 4: Please add a FAN kit (P/N# 98R1752000E) into
i-module, if the PCIe/PCI add-on card power
consumption is over 45W.
• 1 x 12V extra power socket
Note 1: 12V extra power connector supports 25~75W.
Note 2: The total power consumption of the M20 riser card
can support 100W (PCIe x16 socket + PCIe p1-x4
socket + 12V extra power)
Storage
• Internal SATA connector: 1
Note 1: Optional 98R1752010E which is able to install a
2.5” HDD/SSD up to 15mm and occupied 2nd PCIe
slot space.
Environment
• Operating Temperature:
-20 ~ 60°C with 0.7 m/sec air ow with 1 x Industrial SSD,
without PC expansion boards
0 ~ 45°C with 0.7 m/sec air ow with 1 x 2.5” HDD, with-
out PC expansion boards
• Storage Temperature: - 40 ~ 85°C (-40 ~185°F)
• Relative Humidity: 95% @ 40°C (non-condensing)
Mechanical
• i-Module dimensions (H x W x D): 53 x 195 x 240 mm
• With MIC-78 series (H x W x D): 133 x 195 x 240 mm
• With Mount kit (H x W x D): 183 x 195 x 240 mm
Note: We suggest adding an optional system fan (P/N:
98R1752000E) if power consumption of your add-on
card is more than 45W (for better thermal
management).
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
https://www.advantech.com/en/support
This manual is for the MIC-78M20 Rev. A1.
Part No.204178M200 1st Edition
Printed in China September 2025
Specications
