MIC-3332 User Manual 46
Register Address: IO address 44Ch
Register Name: GPIO Output Value
Default Value: 00
Attribute: Read/Write
Note: GPIO setting is reserved, not open.
Register Address: IO address 44Dh
Register Name: GPIO Output Enable
Default Value: 00
Attribute: Read/Write
Note: GPIO setting is reserved.
Register Address: IO Address 44Eh
Register Name: IO Port 80 Status
Default Value: --
Attribute: Read Only
Register Address: IO Address 44Fh
Register Name: Dual BIOS Switch Register
Default Value: 00
Attribute: Read /Write
Bit Description Access
7-0 GPIO[7:0] Output Value, RSVD R/W
Bit Description Access
7-0 GPIO[7:0] Output Enable, RSVD R/W
Bit Description Access
7:0 IO Port 80 status RO
Bit Description Access
7:0
Dual BIOS Switch
00: Boot from BIOS1
01: Boot from BIOS2
Bit7-Manual Control
Other reserved
Example:
want to change flash BIOS1?need to set this register to 0x80;
If want to change flash BIOS2?need to set this register to
0x81.
RW
