45 MIC-3332 User Manual
Appendix C FPGA Specification
Register Address: IO address 447h-448h
Register Name: Revision ID Register
Default Value: 0014
Attribute: Read Only
Register Address: IO address 449h
Register Name: Power Status
Default Value: ----
Attribute: Read Only
Register Address: IO address 44Ah
Register Name: GA Status
Default Value: 00
Attribute: Read Only
Register Address: IO address 44Bh
Register Name: GPIO Input Status
Default Value: 00
Attribute: Read Only
Note: GPIO setting is reserved, not open.
Bit Description Access
0-15
Revision ID
Revision changes announcing design changes and additions
with impact to the CPLD related firmware and application.
RO
Bit Description Access
0 HANDEL# status RO
1 J1 ENUM status RO
2 BD_SEL# status RO
3 System PLTRST# status RO
4 PM_ICH_PWROK status RO
5 System S3# status RO
6 System S4# status RO
7 System S5# status RO
Bit Description Access
4-0 GA status RO
7:5 RSVD RO
Bit Description Access
7-0 GPIO[7:0] Input Status , RSVD RO
