7 MIC-1816 User Manual
Chapter 2 Initial Setup
2.4 Table Mount Installation
MIC-1816 provides an optional table mount kit for flexible deployment. Follow the
instructions below for installation. To avoid overheating, the extruded heat sink must
be installed on top of the system.
1. Undo the 4 x affixing screws of the rear cover.
2. Position the table mount in place, align the screw holes with those in the rear
cover. Secure the mount to the system using 4 x screws.
Optional Table Mount
Part Number: 1960099348N001
Dimensions: 220 x 156 mm (8.66 x 6.14 in.)
