IDK-2108 User Manual 16
4.1 TFT LCD Module
The physical interface described is for the connector on module. These connectors
are capable of accommodating the following signals and components listed.
4.1.1 Connector
4.1.2 Pin Assignment
4.2 Backlight Unit
The physical interface described is for the connector on module. These connectors
are capable of accommodating the following signals and components listed.
4.2.1 Signal for LED light bar connector
Cable Length : 250mm+/-10mm
Table 4.1: LVDS Connector
Connector Name / Description Signal Connector
Manufacturer STM or Compatible
Connector Model Number STM-MSB24013P20HA or Compatible
Adaptable Plug STM-P24013P20
Table 4.2: Pin Assignment
Pin No. Signal Name Pin No. Signal Name
1 VDD 2 VDD
3UD 4 LR
5RxIN1- 6 RxIN1+
7 GND 8 RxIN2-
9 RxIN2+ 10 GND
11 RxIN3- 12 RxIN3+
13 GND 14 RxCLKIN-
15 RxCLKIN+ 16 GND
17 SEL68 18 NC
19 RxIN4- 20 RxIN4+
Connector Name / Designation LED Light Bar Connector / Backlight Lamp
Manufacturer JST or compatible
Type Part Number WF-SMT90 1.5mm Wire to board Heater
Mating Type Part Number NA
Connector No. Pin No. Input Color Function
Lower
CN2
1 HI 2 Red Power supply for backlight unit
2 GND 2 Black Ground for backlight unit
