IDK-1112R-50XGA1 User Manual 10
2.5 Input Terminal Pin Assignments
2.5.1 TFT LCD MODULE
Table 2.3: Table 3.3: Pin Description
Pin Name Description Remark
1 RX3+ Differential Data Input, CH3 (Positive)
2 RX3- Differential Data Input, CH3 (Negative)
3NC NC
4SEL68
LVDS 6/8 Bit Select Function Control,
Low→6 Bit Input Mode
High→8 Bit Input Mode
Note (3) (4)
5 GND Ground
6 RXC+ Differential Clock Input (Positive)
7 RXC- Differential Clock Input (Negative)
8 GND Ground
9 RX2+ Differential Data Input, CH2 (Positive)
10 RX2- Differential Data Input, CH2 (Negative)
11 GND Ground
12 RX1+ Differential Data Input, CH1 (Positive)
13 RX1- Differential Data Input, CH1 (Negative)
14 GND Ground
15 RX0+ Differential Data Input, CH0 (Positive)
16 RX0- Differential Data Input, CH0 (Negative)
17 reLR
Horizontal Reverse Scan Control,
Low →Normal Mode
High→ Horizontal Reverse Scan
Note (3) (4)
18 reUD
Vertical Reverse Scan Control,
Low→Normal Mode
High→ Vertical Reverse Scan
Note (3) (4)
19 VCC Power Supply
20 VCC Power Supply
Note (1) Connector Part No.: STARCONN 076B20-0048RA-G4 or equivalent.
Note (2) User's Connector Part No.: JAE FI-SE20ME or equivalent.
Note (3) "Low" stands for 0V. "High" stands for 3.3V.
