IDK-1107WR User Manual 20
3.1 Signal Description
LVDS is a differential signal technology for LCD interface and high speed data trans-
fer device. The connector pin definition is as below.
Note: “Low” stands for 0V. “High” stands for 3.3V. “NC” stands for “No Connected.”
3.1.1 Signal Description (IDK-1107WR-40WVA1E)
Table 3.1: Symbol Description (IDK-1107WR-40WVA1E)
Pin No. Symbol Description
1 VDD Power Supply, 3.3V(typical)
2 VDD Power Supply, 3.3V(typical)
3 UD Vertical Reverse Scan Control,
When UD=High or NC -> Normal Mode.
When UD=Low -> Vertical Reverse Scan. Note
4 LR Horizontal Reverse Scan Control,
When LR=High or NC -> Normal Mode.
When LR=Low -> Horizontal Reverse Scan. Note
5RxIN1-
LVDS differential data input Pair 0
6RxIN1+
7 GND Ground
8RxIN2-
LVDS differential data input Pair 1
9RxIN2+
10 GND Ground
11 RxIN3-
LVDS differential data input Pair 2
12 RxIN3+
13 GND Ground
14 RxCLKIN-
LVDS differential Clock input Pair
15 RxCLKIN+
16 GND Ground
17 SEL 68 LVDS 6/8 bit select function control,
Low or NC -> 6 Bit Input Mode.
High -> 8 Bit Input Mode. Note
18 NC NC
19 RxIN4-
LVDS differential data input Pair 3. Must be set to NC in 6 bit input
mode.
20 RxIN4+
